GM - 03 / 66203 / Digital panel meter.

GM - 03 / 66203 / Digital panel meter.

SUPPLIER :- Mahavir agenices

Input Current: Selectable/programmable 1 A or 5 A AC input (suitable for CT secondary terminated at 1 A/5 A).

Network: Designed mainly for single-phase electrical network.

Measurement Type: AC current measurement (true RMS depending on internal design).

Digit Count: 4 digit digital display (up to 9999).

Accuracy Class: Class 1.0 (±1% of reading, typical for Rish panel

 meters)

Input1 A / 5 A AC (programmable)
Display14 mm LED, 4 digits
Accuracy ClassClass 1.0
NetworkSingle phase AC
Auxiliary Supply~40–300 V AC/DC
MountingDIN cut-out approx. 48×96 mm
ProgrammableYes — CT ratio & scaling
₹ 1,370.00 ₹ 1,370.00 /NOS  (Tax excluded)


Add to cart
Add to wishlist
Terms and Condition
Payment: 100% Advance
PRICE: Ex-works, Jamshedpur + GST 18 %.
PAYMENTS: 100 % against Performa invoice prior to dispatch.
FREIGHT: In your scope
DELIVERY: Within 90 days, However we will dispatch earlier.
INSURANCE: You shall do Transit insurance at your cost.
VALIDITY: 7 days
WARRANTY: 12 months against manufacturing defect .
